JY-210 Mini diesel purification filter can remove impurities and separate water from oil. It can also protect the nozzle system of engine. As a result, the failure rate will decrease, wear will reduce and the reliability of engine will be improved.
Technical Index:
Model Type: JY-210
Flow Rate: 0~10 L/min (Depends on the quality of oil)
Filtration Level: 1
Filtration Precision: 5,10, 20μm （According to system requirements）
Elements Quantity: 17 Pieces (Assembly)
Working Pressure: 0.2~0.35 Mpa
Temperature Range: -10~70 ℃
Standard Mouth: M14*1.5
Dimension: ? 205*460 mm
Weight: 6.5 Kg
Service Life of Elements: Can be used repeatedly with proper maintenance and timely cleaning
Characteristics:
·High performance diesel purification filter
·Long-acting membrane filtration elements
·High precision and deep filtration
·High rejection rate
·Oil water separation
·Remove free water
·Stainless steel tank
Fuel Polishing Systems for all fuels
The JY-210 diesel turbine fuel filter isdesigned to protect your precious engine components from various contaminantssuch as dirt, rust, algae, asphaltenes, varnishes and water.
