Customer: Hairun Petrochemical Industry Co., Ltd. in Taizhou City, Shandong Province

Problem:  In order to reduce the cost, this company purchase some non-standard diesel and sea oil. As the mechanical impurities and moisture in diesel exceeded seriously, the fuel injectors of tank truck were burned frequently. The maintenance cost is too high, and will affect the normal operation of the machinery.

Solution: Install one set of JY-VX80A Multifunction Diesel Refined Water Removal Equipment to remove metal, colloid and impurities particles in diesel.

Filtration Effect: The color of diesel becomes light, and cleanliness level was improved a lot.

Technical Index:

Model Type: JY-VX80

Flow Rate: 30~40 tons/h (Depends on the quality of oil)

Filtration Precision: 2,5,10,15,20 μm （According to system requirements）

Filtration Material: Jingyuan Polymer Membrane Material(Various types,and can be used repeatedly after washed )

Working Pressure: 0.2~0.3 Mpa

Filtration Efficiency(≥4μm):98%

Voltage: 380V Explosion-proof Motor

Pre-filtration: Y (Two Levels)

Pipeline Diameter: DN80(3′)

Suitable Oil: Light diesel, aviation kerosene

Measurement: 1900*1700*2450mm

The most advanced filtration technology ------------ membrane filtration technology:

The polymer membrane material is different from traditional filtration material, since the lipophilic characteristic of membrane, the oil will pass from inside of the elements, and colloid, impurities and water will be held back on the surface. Therefore, by periodic cleaning, the elements can be used repeatedly, and the service life of them will be 2~3 years. Compared with filter sand, the consumable costs is low, and compared with filter screen, the cleaning process is convenient. So membrane filtration technology is expected to be good in the years ahead!

Shenyang Jingyuan Membrane Systems Co., Ltd. ------ Your Cooperation Partner in Oil Purification

In oil filtration field, Jingyuan is the leader in the research and application of membrane technology, and obtained many patents.

Company management concept: professional as the core, continuous product innovation, strict quality control, and constantly improve the comprehensive benefit of the clients.

We help customers to choose and optimize filtration process from reliability, safety, efficiency and environmental protection.

Our Four Core Process:

Develop and manufacture high quality product, and supply professional solutions and service for customets.

The service we supply on working site is as below:

＞ Debugging and maintenance service

＞ Spare parts service

＞ Provide training lessons for internal professional staff

＞ An 24 hours hotline to answer all your questions about the filtration system
