Customer: DOOSAN Engineering Machinery (China) Co., Ltd.

Problem:  Engineering machinery is always working in the wild environment, the quality of diesel fuel cannot be guaranteed, and will be harmful to the machinery. The frequent replacement of nozzles lead to high cost, and will affects the normal operation of machinery.

Solution:

JY-210 Mini diesel purification filter can remove impurities and separate water from oil. It can also protect the nozzle system of engine. As a result, the failure rate will decrease, wear will reduce and the reliability of engine will be improved.

Technical Index:

Model Type: JY-210

Flow Rate: 0~10 L/min (Depends on the quality of oil)

Filtration Level: 1

Filtration Precision: 5,10, 20μm （According to system requirements）

Elements Quantity: 17 Pieces (Assembly)

Working Pressure: 0.2~0.35 Mpa

Temperature Range: -10~70 ℃

Standard Mouth: M14*1.5

Dimension: ? 205*460 mm

Weight: 6.5 Kg

Service Life of Elements: Can be used repeatedly with proper maintenance and timely cleaning

Characteristics:

·High performance diesel purification filter

·Long-acting membrane filtration elements

·High precision and deep filtration

·High rejection rate

·Oil water separation

·Remove free water

·Stainless steel tank

Installation:

Install the filtration unit on the machinery properly, then connect the oil inlet and oil outlet, and confirm they have been sealed well. As this is the first time the filter to be used, please loosen the air release valve first, and then start the engine, let the diesel pass through the filter. When the filter is filled with diesel, tighten the valve immediately. At this time, all the air in filter has been expelled already; the filter can be used normally.

*Notice：The air must be released before the filter elements to be washed.

Membrane Filter Elements:

If the flow rate decreased significantly（or service over than 350 hours），please take filter assembly out，soak into alkaline or benzene solvent，then brush the surface of elements, and blow the inside of elements with compressed air. In this way, then flow rate can be returned to normal.

*Notice：After using a period of time, please open the drain valve at the bottom of filter to discharge the impurity and water accumulated.
