Application of JY-219A in Engineering Machinery

Problem:

Since engineering machinery were working in wild severe environment, it is difficult to guarantee the quality of diesel fuel. As a result, dirty diesel will effect the running of these machinery.

Solution:

JY-219A is a kind of portable diesel fuel purification filter which can be used in working site for fuel refueling and purification. It has small valume, excellent portability, high precision, deep filtration, high interception rate, low diffrerntial pressure, can remove impurity particles, colloid and water contained in diesel. Clean diesel makes the rate of engine failure decrease significantly, at the same time, efficiency will be improved, maintenance costs will be cut down, fuel consumption reduces 5-10%, oil-saving effect is obvious, the service life of diesel engines extend 2 ~ 3 times.

Technical Index:

Model Type: JY-219A

Flow Rate: 20~40 L/min (Depends on the quality of oil)

Filtration Precision: 2,5,10,15,20μm （According to system requirements）

Filtration Material: Jingyuan Polymer Membrane Material(Various types,and can be used repeatedly after washed )

Working Pressure: 0.2~0.35 Mpa

Filtration Efficiency(≥4μm):98%

Suitable Oil: Light diesel, aviation kerosene

Voltage: 220V/DC24V/DC12V

Measurement: 310*390*670mm

Weight:30Kg

Excellent Characteristics:

·Small volume, excellent convenience, high precision, deep filtration, high rejection rate, low pressure differential

·Be strictly designed and manufactured in accordance with ISO9001 Quality Control System.

Upgrade Model: JY-219D

In order to increase the flow rate, we make 2 sets of JY-219A parallel connection, upgrade to a new model JY-219D.

Since the flow rate increased to 2 times than before, the filtration time has been greatly shortened and the efficiency is also improved.

Application Field:

Be suitable for oil depot,small diesel refinery, concrete mixing plant,transportation company owned oil storage tank, railway station oil depot, gas station, engineering machinery owned oil storage tank, mining machinery owned oil storage tank,construction site diesel supply station, large scale generator unit,oil loading filtration and oil unloading filtration and so on.
