Mining Area Temporary Gas Station Diesel Purification and Filtration Case

Customer：The construction site of a large state enterprise in Kenya

Vehicle Model: Forklift, Excavator,Bulldozer, Heavy Duty Truck, Heading Machine and so on.

Problem: The mining areas were located in Kenya, since various reasons, the quality of diesel cannot be guaranteed. Engineering machinery is always working in the wild environment, is harmful to the normal using. The frequent maintenance leads to high cost, and the normal production will be affected.

Solution:

Install one set or several sets of JY-T32/JY-T32A Diesel Purification Filter to remove impurity, colloid and water from diesel. Clean diesel makes the  engine failure rate decrease significantly, at the same time, efficiency will be improved, maintenance costs will be cut down, fuel consumption reduces 5-10%, oil-saving effect is obvious, the service life of diesel engines extend 2 ~3 times. Engineering Mechanical Diesel Engine Station 3 will be carried out since January 2016, the use of clean diesel is imperative.

Effect:

Clean diesel makes the failure rate of engine decrease significantly, at the same time, efficiency will be improved, maintenance costs will be cut down, fuel consumption reduces 5~10%, oil-saving effect is obvious, the service life of diesel engine extends 2~3 times.

Technical Index:

Model Type: JY-T32

Flow Rate: 40 L/min

Filtration Precision: 2,5,10,15,20μm （According to system requirements）

Filtration Material: Jingyuan Polymer Membrane Material(Various types,and can be used repeatedly after washed )

Working Pressure: 0.2~0.35 Mpa

Filtration Efficiency(≥4μm):98%

Filtration Level: 2

Power Supply: No motor and pump unit

Suitable Oil: Light diesel, aviation kerosene

Measurement: 660*350*650 mm

Weight: 49Kg

Model Type: JY-T32A

Flow Rate: 40 L/min

Filtration Precision: 2,5,10,15,20μm （According to system requirements）

Filtration Material: Jingyuan Polymer Membrane Material(Various types,and can be used repeatedly after washed )

Working Pressure: 0.2~0.35 Mpa

Filtration Efficiency(≥4μm):98%

Filtration Level: 2

Voltage:220V/380V

Suitable Oil: Light diesel, aviation kerosene

Measurement: 680*480*660 mm

Weight: 64Kg

* The only one difference between JY-T32 and JY-T32A is that, there is a power supply system  in JY-T32A, but JY-T32 has no.

Environmental Protection Trend:

Engineering machinery diesel engine State 3rd Standard will be carried out since Jan.,2016, the application of clean diesel is imperative.

Application:

Be suitable for oil depot,small diesel refinery, concrete mixing plant,transportation company owned oil storage tank, railway station oil depot, gas station, engineering machinery owned oil storage tank, mining machinery owned oil storage tank,construction site diesel supply station, large scale generator unit,oil loading filtration and oil unloading filtration and so on.

Upgrade Model: JY-M50 /JY-E50

On the basis of JY-T32, we add a trolley design to make the equipment move easier.

JY-M50 is equipped with a 380V Electronic Pump Unit and JY-E50 is equipped with a HONDA GX160 5.5HP Gasoline Engine.

* JY-M50H and JY-E50H are for the purification of hydraulic oil, engine oil, gear oil, lube oil and other industrial oils.
