Coastal Areas Diesel ( Sea Oil) Filtration / Water Removal Case

Customer: Hengtai Petroleum Co., Ltd. in Dongguan City, Guangdong Province

Problem:

As a large amount of contamination particles and free water contained in diesel, the color of it is poor and opacity .

Solutions:

Install one set or several sets of JYDFS15A Highperformance Diesel Purification Filter for diesel filtration and water removal. We should discharge the contamination from bottom of tank every day, and back-wash the filter every 30 days. The service life of filter element will be 2~3 years.

JY-DFS15 High-performance Diesel Purification Filter

Model Type: JY-DFS15

Flow Rate: 10~15 m3/h

Filtration Precision: 2,5,10,15,20μm （According to system requirements）

Filtration Material: Jingyuan Polymer Membrane Material(Various types,and can be used repeatedly after washed )

Working Pressure: 0.2~0.35 Mpa

Filtration Efficiency(≥4μm):98%

Water Separation Rate:98%

Pipeline Diameter: DN65(2.5′)

Measurement: 1600*800*2010mm

Specially designed for diesel purification.According to the characteristics of light diesel, especially the diesel content a lot of water, we adopt high performance membrane filtration technology to refine the diesel,as well as to remove the impurities, colloid from oil. For the marine diesel which contents a lot of free water and particles, the separation effect is obvious.The service life of elements is long, and the quality level of diesel can be upgraded.

Quality Guarantee and Reliability:

＞ All of Jingyuan membrane filters are produced with high quality, and meet the manufacturing standard.

  As a result,our filters will run efficiently and safely.

＞ All products are strictly designed and manufactured in accordance with ISO9001 Quality Control System.

Relative Product: JY-C500-20 Large Capacity Diesel Demulsification Refining System

JY-C500-20 is designed for the purification of emulsifed diesel.

· To break the emulsified structure and deeply filtrate the  oil.

· There are 3 levels filtration to purify the diesel, and the water separation rate is more than 98% .

· Siemens 380V Explosion-proof Motor and Italy imported Screw Pump.

· 304 Stainless Steel Tank
