Customer: One oil depot in Chaoshan, Guangdong Province
Problem: In order to reduce the cost, this company purchase some non-standard diesel and sea oil. As the mechanical impurities and moisture in diesel exceeded seriously, the fuel injectors of tank truck were burned frequently. The maintenance cost is too high, and will affect the normal operation of the truck.
Solution: Install one set of JY-DFS65A Large Capacity Diesel Refined Water Separator to remove water, impurities and colloid from diesel.
Effect: The oil becomes transparent and clear, and the failure rate of engine decrease significantly, at the same time, efficiency will be improved, maintenance costs will be cut down, fuel consumption reduces 5~10%, oil-saving effect is obvious, the service life of diesel engine extends 2~3 times.
Technical Index:
Model Type: JY-DFS65A
Flow Rate: 30~40 tons/h (Depends on the quality of oil)
Filtration Precision: 2,5,10,15,20 μm （According to system requirements）
Filtration Material: Jingyuan Polymer Membrane Material(Various types,and can be used repeatedly after washed )
Working Pressure: 0.2~0.3 Mpa
Filtration Efficiency(≥4μm):98%
Voltage: 380V Explosion-proof Motor
Pre-filtration: Y (Two Levels)
Pipeline Diameter: DN80(3′)
Suitable Oil: Light diesel, aviation kerosene
Measurement: 1900*1700*2450mm
·Solve the oil turbidity caused by micro particulates, impurities, water and colloid.
·Remove lots of water and sediment from distillation diesel and catalytic kerosene.
·Diesel becomes clear and bright after refined by membrane elements.
·High-efficiency, energy-saving and environmental protection.
Application:
Be suitable for oil depot,diesel refinery, concrete mixing plant,transportation company owned oil storage tank, railway station oil depot, gas station, engineering machinery owned oil storage tank, mining machinery owned oil storage tank,construction site diesel supply station, large scale generator unit,military industry,nuclear power,power plant, oil extraction plant,oil loading filtration and oil unloading filtration and so on. At the same time, our products are also used in Africa and Middle East for State Enterprises and China-invested Enterprises.
Quality Guarantee and Reliability:
＞ All of Jingyuan membrane filters are produced with high quality, and meet the manufacturing standard.
As a result,our filters will run efficiently and safely.
＞ All products are strictly designed and manufactured in accordance with ISO9001 Quality Control System.
FAQ about our company and product:
1.Q：Are you a manufacturer?
A：Yes, we are the manufacturer with continuous and improved R&D, production, sales and service supply.
2.Q: What’s the price range of your product?
A：According to different flow rate, the price of our product is between USD 300~37,000.
Q: Can I get your price list?
A: Yes, sure. In order to send you our available offered price, please choose the products and let us know the product model and requirement in detail.
3.Q：What kind of oil can be filtered?
A: What we specialized in is diesel fuel filtration, as well as engine oil, gear oil, hydraulic oil, lube oil, turbine oil, aviation kerosene and so on.
4.Q：Compared with traditional filters, what is the advantage of Jingyuan?
A：The development of Jingyuan high performance membrane provides the core filtration material for our product. This material has large flow rate, high precision and long service life, can be used repeatedly after cleaned.
5.Q：How long is the delivery time?
A：Usually, the delivery time is 5~7 days after full payment in advance.
6.Q：Which voltage is suitable for Jingyuan filtration product?
A: According to your actual requirements, we will select 380V/220V/DC24V/DC12V motor pump group for you. At the same time, we will also supply the gasoline engine for the working site without power supply system.
7.Q：What certification did the product get?
A：First of all, our company has applied for proprietary technology and all of our product have independent intellectual property rights. And we also have passed ISO 9000 Quality Control System, European Union CE Certification and Swiss SGS Certification.
8.Q：Which model is suitable in small gas station?
A：For the small gas station which capacity is less than 20 tons per day, we recommended JY-219/219A, JY-T32/T32A for you.
9.Q：Which model is suitable in large oil depot?
A：For the large oil storage tank which capacity is more than 150 tons per day, we recommended JY-VX Series or JY-DL Series for you.
10.Q：Which model is suitable for marine oil?
A：We recommended JY-T100 multistage filtration unit for diesel with high water content, and JY-H130/230/330/180 is for industrial oils.
11.Q：How about the filtration effect?
A：The oil becomes clear and transparent, and the cleanliness can meet the State IV Standard and NAS Class 7.
12.Q：How to install the filtration device? Is there any technical staff for guidance?
A：Normally, you only need to connect the inlet and outlet of our device to the filling pipe and outlet pipe. We will also provide a detail operation instructions to guide you how to use the machine. We may also arrange a professional technical staff to provide service on site, but you need to pay for it.
13.Q：How long is the service life of your product/ filter elements ? And how to clean them?
A：The service life of elements will be 2~3 years under regular maintenance, and the blocked elements can be used repeatedly after back flushing by compressed air.
14.Q: What’s your after-sales policy(The terms of guarantee)?
A: The period of quality guarantee is 1 year ( except the filter elements)
15.Q: What’s your payment policy?
A: Samples ( Less than USD 4,000)：100% payment in advance via T/T or West Union
Formal Order ( More than USD 4,000): 30% payment in advance via T/T as deposit payment and balance payment will be done against the Copy of B/L . L/C payment is also available.
16.Q: Can I get your products with my logo and design?
A: Most of products are OEM or ODM with your logo.
Any other questions, please feel free to contact us through 7*24 hours online service or send us inquires by mail.
